LineX MAX PRO
INS-LXM-656-10GM-36L-WD7
Key Feature
Resolution (DPI)
3600
Accuracy (μm)
7
Line Frequency (kHz)
40
Interface
10GigE
FOV (mm)
656
Options
Mono or Color
Mono
Ethernet Port
4
WD (mm)
7
Specifications
Downloads
Drawing
Information
Mono or Color
Mono
Interface
10GigE
FOV (mm)
656
Resolution (DPI)
3600
Accuracy (μm)
7
DOF (mm)
± 0.7
WD (mm)
7
Line Rate (kHz)
40
WS (m/s)
0
Ethernet Port
4
Pixel (k)
93
Size
730mm*105mm*108mm
Specifications
Information
Mono or Color
Mono
Interface
10GigE
FOV (mm)
656
Resolution (DPI)
3600
Accuracy (μm)
7
DOF (mm)
± 0.7
WD (mm)
7
Line Rate (kHz)
40
WS (m/s)
0
Ethernet Port
4
Pixel (k)
93
Size
730mm*105mm*108mm
